Modular Jack Connectors for High-Speed LAN Transmission
TM21R Series
Built-in Optical Indicators
LED
Optical indicator
Optical pipe
s Features
1. Supports High-Speed LAN Transmission
Meets requirements of TIA/EIA-568-B data wiring
standard. Single port configuration meeting CAT5e and
multiple port configuration meeting CAT5 transmission
performance.
Housing
Optical indicator area
As such, these products fully support Gigabit Ethernet
(1000BASE-T) and Fast Ethernet (100BASE-TX) high-
speed LAN transmission.
2. Built-in Optical Indicators
Optical indicators are integral part of the connectors
saving space on customer’s board.
Compared with LED type indicators, they do not emit any
electrical noise.
3. EMI protection
Metal shield covers the outer surfaces of the connectors
assuring complete protection against electromagnetic
interference.
Built-in multiple shield and ground contacts assure
reliable connection with the mounting panel as well as
with the mating connector.
4. FCC Standards
Meets requirements of FCC Title 47, Part 68, Subpart F.
Space
saving
Optical indicator
One additional TM21 multi-port jack can be mounted
in the space previously occupied by LEDs.
s Applications
Telecom Hubs, Routers, Bridges and ATM Transmission
Equipment, Ethernet Switches and Networking Equipment,
Test and Measurement Equipment, Medical Diagnostic
Equipment.
Built-in LED type
(Possibility of
electromagnetic noise
emission and
interference.)
Built-in Optical pipe
type
(No electromagnetic
noise emission.)
2012.6
1
